Description
Integrated Crushing, Pressing, and Dewatering Machine
.jpg)
Technical Parameter
| Model | Capacity（t/h） | screw diameter（mm） | rotate speed（r/min） | Power（kw） | Dimensions: length * width * height（mm） | Weight（t） |
| ZTZY-120 | 0.1～0.3/0.26 | 120 | 30 | 2.2/3 | 1900×420×700 | 0.5 |
| ZTZY-180 | 0.3～1/0.5 | 180 | 20 | 5.5 | 2500×550×800 | 0.8 |
| ZTZY-250 | 0.8～3/0.93 | 250 | 16 | 7.5 | 3100×650×900 | 1 |
| ZTZY-315 | 2～5/1.6 | 315 | 16 | 11 | 4100×790×1320 | 2 |
| ZTZY-400 | 5～13/2 | 400 | 10 | 22 | 4700×990×1420 | 4 |
| ZTZY-500 | 8～18/3.3 | 500 | 9 | 37 | 6100×1200×1500 | 6 |
| ZTZY-630 | 15～35/4.2 | 630 | 9 | 45 | 6800×1350×1650 | 7.5 |
| ZTZY-800 | 25～50/7 | 800 | 7 | 75 | 7500×2300×2200 | 9 |
| ZTZY-1000 | 30～70/8.5 | 1000 | 6 | 90 | 8100×2700×2600 | 12 |
Features
- Multifunctional Integration: Combines crushing, pressing, and dewatering in one unit, reducing footprint, investment costs, and boosting productivity.
- High Efficiency & Energy Savings: Advanced crushing and pressing technologies minimize energy consumption while maximizing processing efficiency, juice yield, and dewatering rates.
- Adaptability: Adjustable parameters (screw shaft speed, pressing gap, crushing intensity) allow customization for diverse material types and processing requirements.
- Easy Maintenance: Compact design with modular components simplifies disassembly, cleaning, and upkeep, lowering operational costs and downtime.
Working Principle
Crushing Part:
Material enters the crushing zone, where high-speed rotating blades or hammers break down large chunks into smaller particles or fragments.
Pressing Part:
The crushed material moves into the pressing zone. A rotating screw shaft applies compressive force to extract liquid or juice, achieving solid-liquid separation.
Material enters the crushing zone, where high-speed rotating blades or hammers break down large chunks into smaller particles or fragments.
Pressing Part:
The crushed material moves into the pressing zone. A rotating screw shaft applies compressive force to extract liquid or juice, achieving solid-liquid separation.
Application
- Food Industry:
-Oil extraction and dewatering of meat, fish, and seafood.
-Processing tea leaves residue, coffee grounds, and other food byproducts.
- Pharmaceutical Industry:
-Dewatering and separation of medicinal residues.
- Chemical Industry:
-Sludge dewatering in wastewater treatment processes.
- Environmental Protection:
-Solid-liquid separation to simplify downstream waste handling and reduce costs.
