Description
Dewatering Screw Press ZTZY-120
Screw extrusion dehydrator adopts the principle of superposition compression, widely used in the chemical industry. When the machine operating, it rotate slowly and no temperature rise. The main effect of the dehydrator are as follows:
Zhongtian Xinghuo machinery has professional technology to produce screw press dewatering machine!
- For some materials to be recycled, this screw press extruders can fully separate solids and liquids to maximize your recycling value.
- For some materials that need to be handed over to a third party, your disposal costs can be reduced by processing with a this screw press dehydrator.
- For some materials that need to be made into finished products, the back-end treatment energy consumption can be reduced through the treatment of the screw extrusion dehydrator.
Zhongtian Xinghuo machinery has professional technology to produce screw press dewatering machine!
Technical Parameter
| Model | Capacity（t/h） | screw diameter（mm） | rotate speed（r/min） | Power（kw） | Dimensions: length * width * height（mm） | Weight（t） |
| ZTZY-120 | 0.1～0.3/0.26 | 120 | 30 | 2.2/3 | 1900×420×700 | 0.5 |
| ZTZY-180 | 0.3～1/0.5 | 180 | 20 | 5.5 | 2500×550×800 | 0.8 |
| ZTZY-250 | 0.8～3/0.93 | 250 | 16 | 7.5 | 3100×650×900 | 1 |
| ZTZY-315 | 2～5/1.6 | 315 | 16 | 11 | 4100×790×1320 | 2 |
| ZTZY-400 | 5～13/2 | 400 | 10 | 22 | 4700×990×1420 | 4 |
| ZTZY-500 | 8～18/3.3 | 500 | 9 | 37 | 6100×1200×1500 | 6 |
| ZTZY-630 | 15～35/4.2 | 630 | 9 | 45 | 6800×1350×1650 | 7.5 |
| ZTZY-800 | 25～50/7 | 800 | 7 | 75 | 7500×2300×2200 | 9 |
| ZTZY-1000 | 30～70/8.5 | 1000 | 6 | 90 | 8100×2700×2600 | 12 |
Advantage
1.Continuous operation, save human cost.
2.Low speed stable operation, material temperature does not rise.
3.Dewatering juice for organic materials
4.Separate slag and liquid for inorganic materials
5.Adopts the superposition compression principle, not blocking screen stencil.
6.High dehydration rate or juice rate, some fruits and vegetables reach 85% juice rate, some materials after dehydration dry up to 20%, to achieve good press effect.
7.Suitable for long, short, hard, soft, smooth, sticky, astringent, thin, thick, granule, powder any material.
8.High pressure spraying, no need take down screen, easy to clean.
Working principle
The dewatering screw press is designed according to the superposition compression principle, mainly achieves the purpose of material press separation by the cooperation of the feeding box, spiral, screen stencil and tail cone.
Material to be treated is uniformly transported to the inlet of the dewatering screw press equipment, by means of a pump or a spiral conveyor, filtered by a spiral blade and screen, then water or juice is collected through a sieve to a water tray below the machine.
After being taken up by the pipeline, the slag separated by the press is conveyed to the storage place through the conveyor belt.
Material to be treated is uniformly transported to the inlet of the dewatering screw press equipment, by means of a pump or a spiral conveyor, filtered by a spiral blade and screen, then water or juice is collected through a sieve to a water tray below the machine.
After being taken up by the pipeline, the slag separated by the press is conveyed to the storage place through the conveyor belt.
Application
It is a special extrusion machine for reducing and dewatering all kinds of chemical materials, such as, dry film residue, paint residue, PVDF Teflon, latex, coal oil residue, activated carbon etc. The extrusion dryness up to 20%. The strength of extruder can be adjusted according to material strength and pH value. It has features of no blocking, no material return.
